Buyer's guide: Your guide to the Chapter 8 regulations

This guide is provided based on extracts from Chapter 8 of the Traffic Signs Manual - it is designed to help you buy the right products for your operational requirements.

For further information on Chapter 8 and specifying the required lighting and markings for your vehicle, please contact us...



Below is a link to the Gov Chapter 8 guide:

Full chapter 8 guide





O5.3.1 Without prejudice to the specific requirements of the following sections, any vehicle stopping on the highway for works purposes or inspections shall be equipped with either a roof-mounted flashing amber warning lightbar (comprising at least two independent light sources) or two independent roof-mounted flashing amber warning beacons, visible through 360°.

O5.3.2 Roof-mounted flashing amber warning beacons must comply with the requirements of the Road Vehicle Lighting Regulations and should also comply with the United Nations Economic Commission for Europe (UNECE) Regulation 65 on Special Warning Lamps.

O5.3.3 If the main roof-mounted beacon is likely to be obscured from the rear by parts of the vehicle or any equipment carried on the vehicle, additional beacons should be fitted toward the rear of the vehicle where they will remain visible.

O5.3.4 The roof-mounted beacons shall be in use when entering, leaving or moving within the site, when travelling in traffic at less than the general traffic speed, and when stationary on the hard shoulder.

O5.3.5 When stationary within the confines of a fully installed traffic management arrangement, the roof-mounted beacons shall be switched off, unless they form part of the guarding of the works, e.g. works on minor roads, or are required for mobile works; see Sections O10 and O11.

O5.3.6 Vehicles engaged on snow clearing, gritting operations or similar work shall display a flashing amber warning beacon at all times when operating.





O5.1.1 Production vehicles are rarely suited to site work in their standard form, so before purchasing a vehicle, consideration should be given to the model‘s suitability for modifications and its ability to carry the necessary equipment. The ease with which an operator can move from the off side seat to the near side door should also be considered.

O5.1.2 The choice of vehicle type, engine size and gearbox should reflect the acceleration and manoeuvrability required of that vehicle during normal working conditions.

O5.1.3 All vehicles and equipment shall be checked for correct operation before work commences. All checks should be documented and all faults reported prior to work commencing. If necessary, the vehicle or equipment should be taken out of service until faults are rectified. Basic vehicle checks should always include fuel, lights, oil, water, electrics and tyres.

O5.1.4 All site vehicles should, where practicable, have all round visibility, for example, estate cars should be used in preference to vans. Where this is not practicable, additional mirrors should be fitted to eliminate blind spots.







05.2.1 Any vehicle stopping on the highway for works purposes or inspections should be of a conspicuous colour (e.g. yellow or white). A non-reflective yellow is recommended.

05.2.2 Subject to the specific requirements of the following sections, any works vehicles that are used to protect the workforce or form part of the signing of the works should be of conspicuous colour and appropriate marking. This is particularly important for that part of the vehicle visible to drivers and prescribed as part of any sign mounted on the vehicle.

05.2.3 In addition, on high-speed roads all vehicles stopping on the highway for works purposes or inspections shall be equipped with high visibility rear markings. High visibility rear markings should comprise either:
a) Signing to diagram 7403, or
b) The alternative light arrow sign in accordance with section 010.8, or
c) Chevron markings comprising alternate strips of fluorescent orange-red retro reflective material and fluorescent yellow non reflective material, of not less than 150mm width each inclined at 45 . 60 degrees to the horizontal and pointing upwards, or
d) A solid block of fluorescent orange-red retro reflective material.
The markings described in ( c ) and ( d ) above should cover as much of the rear-facing portion of the vehicle as possible without obscuring windows, vehicle lighting or registration plates.

05.2.4 Red retro reflective tape shall also be applied to all rear facing edges of open doors, guardrails and equipment lockers.

05.2.5 Where rear facing high visibility markings may be obscured by any device mounted on the vehicle (e.g. lorry-mounted crash cushion (LMCC) or cone laying adaptation), at any time that the vehicle is stopped on a high-speed road additional markings complying with paragraph 05.2.3 ( c ) or ( d ) shall be applied to any face of the device which is displayed to the rear and other road users.

05.2.6 Works vehicles should be kept clean to maintain conspicuity.

05.2.7 Motor vehicles with a maximum gross weight exceeding 7.5 tonnes and trailers with a maximum gross weight exceeding 3.5 tonnes must be fitted with rear markings in accordance with the Lighting Regulations.

05.2.8 Maintenance vehicles shall be identified by displaying to the rear, the sign to diagram 7404 "HIGHWAY MAINTENANCE". The sign to diagram 7404 variant "MOTORWAY MAINTENANCE" may be used instead when working on motorways only.

05.2.9 Other plant and equipment should be painted in a conspicuous colour.
